Appendix D: Nightmare on Elm Street - The model subroutines.

appendixD

The scope of this user guide is to give an indication of how things work without explaining every line of the code. The main body of the program has already been presented in Appendix A. Here the subroutines get a similar treatment, in the order they currently appear in the source code.

INISET: Called just once at the beginning of the run to set up basic constants and default values of namelist variables. It then reads the SETUP namelist to override the defaults. SETUP has just five variables which are used for basic run types. The user modifiable code setup.f is then included. It uses the namelist SETUP, and overrides the defaults in the namelist INITIAL. Then INITIAL is read and this overrides both defaults and whatever has been set in the setup file. This way, what you see is what you get in the job script. The subroutine goes on to calculate basic indices, horizontal diffusion coefficients and non-dimensionalising factors and coefficients for calculating derivatives in from spectral coefficients. Finally it sets up all the non-dimensional time scales and associated rates for model parameterised processes.

INIGAU: Called just once at the beginning of the run. Calculates Gaussian weights and latitudes.

INISI: Called just once at the beginning of the run. Sets up the sigma levels from specified sigma half levels. Then sets up alpha weights used for calculating the geopotential in the gravity wave source term, see fig. A2.

INIRES: Called just once at the beginning of the run (the name is historical, this routine is no longer used for restoration forcing). Contains some setup for the vertical profile of vertical diffusion coefficients. These are calculated according to the specified timescales and introduced into the profile PRDAMP. Also sets up the vertical profile for convective heating using input parameter PRHEATMAX. This profile is written into PRHEAT.

INIVAR: Called just once at the beginning of the run. Initialises model variables. First single-level grid variables: masks, precipitation diagnostics and SSTs. Then multi-level grid variables. Then reads in the land-sea mask. Sets up a latitude-dependent function CD for the boundary layer vertical diffusion. Then defines regional masks for SSTs and nudging. Finally (and redundantly) initialises all spectral variables to zero, including tendencies.

INIIC: Called at the start of each run, which is once per initial condition if we are in a training loop, but only once for a normal run. Initialises all spectral variables to zero, including tendencies. Initialises gridpoint output diagnostics to zero. Reads the initial condition from channel 10 and sets up the model year RMYR. Initialises previous timestep spectral variables to be the same as the initial condition.

INITEND: Called at the beginning of the adiabatic part of the timestep and again at the beginning of the diabatic part. Initialises all spectral tendencies to zero.

INIQCON: Called each time the forcing and reference state is updated and also at the beginning of the adiabatic part of the timestep. Initialises the spectral moisture flux convergence to zero.

READFCE: Called at the start of each run and each time the forcing and reference state is updated. Reads forcing (channel 13) and reference states (channel 16). Takes their zonal mean if LZMFC enabled. Performs calculations to modify the forcing of humidity and temperature if LCHX is enabled (wet run). This entails wave to grid transformations using spectral workspace variables and gridpoint moisture and temperature variables QG and TG temporarily. The modified forcing is defined in grid space as the positive only source of Q and an adjusted heating for T. Wave to grid transformations are also made to store gridpoint values of the reference state. Moisture flux convergence is truncated to smooth it before finally going back to grid space to store a gridpoint reference value of the moisture flux convergence.

READNUDGE: Called at the start of each run and each time the nudging state is updated. Reads the spectral nudging state from channel 20.

READFAN : Called at the start of each run and each time the forcing anomaly is updated. Reads the spectral forcing anomaly from channel 15. Rewinds if at end of file.

INISSTC: Called at the start of each run. Initialises grid climatological SST by reading from channel 18. Scrolls through the data until it picks up the correct record for the month KBEMNSST.

READSSTC: Reads grid climatological SST from channel 18 each time it is updated. Will stick on the last record unless LOOPSST is enabled in which case it will rewind at the end of the file.

INISST (MREMAIN): Called at the start of each run. Reads grid SST data from channel 17. If the SST data contains metadata the it initialises SST at correct year and month specified by KBEGYRSST and KBEGMNSST. Otherwise it just reads the first record of SST data. Calculates the right value of RMYR to pass the correct calendar date to the diagnostics. Passes back MREMAIN, the number of days to wait before reading again, to the main program to offset the counter for reading SST data.

READSST Reads grid SST from channel 17 each time it is updated. Will stick on the last record unless LOOPSST is enabled in which case it will rewind at the end of the file. Handles SST data with or without metadata.

SPECPREP: Called just before the diabatic tendencies are calculated. Calculates smoothed values of Q and Q flux convergence by spectral truncation.

SPECPOST: Called immediately after the diabatic tendencies are calculated. Sets global mean spectral coefficients of diabatic tendencies of vorticity, divergence and surface pressure to zero.

FANDAMP: Called before the diabatic timestep. Adds in spectral tendencies from the forcing anomaly. If LPULSE is enabled a sin-squared temporal pulse is imposed on the anomaly amplitude at the beginning of the run, otherwise it is time-independent. If LSTAB is enabled an additional damping is applied equally to all spectral tendency coefficients.

DIFUSE: Called before the diabatic timestep. Adds spectral tendency due to scale-selective hyperdiffusion.

DSTEP: The diabatic timestep. Updates spectral variables with accumulated diabatic tendencies.

FSTEP: Called immediately after the diabatic timestep. Updates spectral variables with basic empirical forcing tendencies.

TFILT: Called at the end of the model timestep. Completes the time filter by modifying the previous values of the spectral variables, ZMI etc.

HANAL: Called from numerous places during grid to wave transformations, notably the subroutine LTD and its derivatives. Used in direct Legendre transforms in to calculate Legendre coefficients for the latitudinal structure from variables in latitude-Fourier space. Different types of transform are used to obtain the fields or their derivatives for variables with differing symmetries.

HANAL1: As HANAL but for single-level fields.

HEXP: Called from numerous places during wave to grid transformations, notably the subroutine LTI and its derivatives. Used in inverse Legendre transforms in to calculate variables on Gaussian latitudes / Fourier space from spectral space. Different types of transform are used to obtain the fields or their derivatives for variables with differing symmetries.

HEXP1: As HEXP but for single-level fields.

LGNDRE: Called from INIGAU. Calculates Legendre polynomials and their derivatives as a function of latitude.

LTD: Called from G2WA. Similar routines are called elsewhere during grid to wave transformations. Stands for Legendre Transform Direct. Transforms from latitude-Fourier space to grid space for a number of variables in order to calculate spectral tendencies for the first part of the time step. Includes multiple calls to HANAL to achieve this, with various requirements to take meridional derivatives as part of the transformation.

LTI: Called from W2GA. Similar routines are called elsewhere during wave to grid transformations. Stands for Legendre Transform Indirect. Transforms from grid space to latitude-Fourier space for a number of variables in order to provide basic gridpoint fields for the calculation of tendencies in grid space. Includes multiple calls to HEXP to achieve this, with various requirements to take meridional derivatives as part of the transformation.

MATINV: Called from INISI when setting up arrays for the semi-implicit scheme. Inverts a matrix.

W2GA: Called from the adiabatic part of the timestep. Collects together the wave to grid operations in the adiabatic part of the time step, calling LTI for meridional (spectral to latitude-Fourier) and FFT991 for the zonal (latiude-Fourier to grid) part of the transformation. Returns grid point model variables.

G2WA: Called from the adiabatic part of the timestep. Collects together the grid to wave operations in the adiabatic part of the time step, calling FFT991 for the zonal (grid to latiude-Fourier) and LTD for meridional (latitude-Fourier to spectral) part of the transformation. Returns spectral fields that will be further manipulated to find the spectral tendencies.

W2GD: Called from the diabatic part of the timestep. As W2GA but for grid point variables needed in diabatic calculations, including instantaneous and reference moisture flux convergence.

G2WD: Called from the diabatic part of the timestep. As G2WA but for grid point tendencies derived from diabatic calculations.

ADVECTION: Called from the main program after wave-to grid transforms in the adiabatic part of the timestep. Calculates all the advective tendencies with variable names marked in red on fig. A1.

SPDEL2: Called from LTD to find the EKE term in the divergence equation. Calculates the Laplacian (or inverse Laplacian) of a spectral variable.

TSTEP: Called just after the first set of spectral transforms that evaluate the advective tendencies in the main program. This subroutine basically implements the equations in HS75 in spectral space. It has nested loops for hemisphere, zonal wavenumber m and meridional wavenumber n.

Briefly:

After setting up a few local variables, such as RCN=1/n(n+1) there are several calls to the matrix multiplier SGEMM. These evaluate variables like RMPA=TTR*G(the first part of the term in HS75 eq 17) and TMPG=TMI*G (the geopotential in HS75 eq 11).

Then a vertical integral to find :

D1 = 1/Cn DMI + DELT*[ PHI + (250/CT)*SPMI + 1/Cn DT(from advection) ]
              + DELT^2*[ TT(from advection)*G + (250/CT)*curlyP ]

where curlyP = V.grad log p* and is equal to -VP.

Then another matrix multiplication to get the left hand side of HS75 eq (17):

DT = D1 * BM1(IBM1+1)

Note that DT is used here to store the mean divergence, not the tendency !

Then a vertical sum to get the tendency of log p* (HS75 eq 4): VP(I1)=VP(I1)+DT(K)*DSIGMA(L)

Then another matrix multiplication to get TMPA=DT*TAU: to build the semi-implicit temperature tendency from HS75 eq (14).

This is added to TT, and then the rest of the subroutine basically adds in the advection, integrating with the time filter in triplets of lines like :

ZPAV=ZMI(I)
ZMI(I)=PNU21*Z(I)+PNU*ZPAV
Z(I)=ZPAV+DELT2*ZT(I)

And thus the model variables have been updated, and so have the pervious timestep versions, with just a time filter to close, which is done in the subroutine TFILT.

WRSPS: Legacy routine to print out spectral coefficients

SCALEDOWN: Called from the main program after the timestep has been completed. Activates the modefinder, which compares a quadratic norm in vorticity with its reference value. If this ratio exceeds 10, the difference between the model state and the reference state is scaled down by this ratio so the anomaly returns to its standard magnitude. This scaling is applied to both current and previous model state. If the ratio is less than 0.1 the anomaly is scaled up.

LTIUVTPQ: Called during wave to grid transformations in the diabatic part of the time step. See LTI.

LTDUVTPQ: Called during grid to wave transformations in the diabatic part of the time step. See LTD.

DIABATIC: Called from the main program after wave-to grid transforms in the diabatic part of the timestep. This is the master subroutine for calculating diabatic tendencies in grid space. Each call to DIABATIC is for a vertical slice of grid data at north and south latitude pair JH (see Appendix A section 2). First all the grid point tendencies are initialised to zero. Then in sequence:
- The nudging tendencies are evaluated directly.
- The moisture flux convergence is calculated in PWATER and the deep convective tendencies are calculated in DEEPTEND.
- The influence of SST is calculated with first another call to PWATER and then SSTTEND.
- The vertical diffusion is evaluated in VDIFFTEND.
- Land-sea drag is added directly.
- Large scale rain tendencies are calculated in LSRTEND.

For each process, the gridpoint values of the model variables are updated as we go, so tendencies calculated for each process are influenced by the previous processes.

Finally the radiative cooling is applied directly and all the tendencies are added up to be passed back through to spectral space.

SHUFFLE: Called from the main program for grid variables just after the diabatic tendencies have been evaluated in DIABATIC. Places the two-latitude slice data in a global gridpoint array.

SHUFFLE1: As shuffle but for single level data.

LTIUVTPQREF: As LTDUVTPQ for reference data.

LTIUVTPQNDG: As LTIUVTPQ for nudging data.

LTDQCONREF: As LTD for Q flux convergence reference data.

LTDQTFCE: As LTD for forcing data.

LTIQCONREF: As LTI for Q flux convergence reference data.

LTIQTFC: As LTI for temperature and humidity forcing data.

TRUNCATE(XTRUNC): Called from READFCE and SPECPREP an applied to specific humidity Q and its convergence. Truncates spectral variable XRUNC from NN to NNTRUNC by packing with zeros.

TRUNCATE1(XTRUNC): As TRUNCATE for single level data - by default not used.

ZMEAN(ZWK,DWK,TWK,SPWK,QWK): Called from INIIC and READFCE. Takes the zonal mean of the entire model state passed to the work arrays. Can also be used for forcing data. Global namelist options control symmetry: ISYM=1 for the full zonal mean and ISYM=0 for a zonal mean that is symmetric about the equator. IWAVE adds wavenumbers 1, 2 and 3 (see Appendix C).

PWATER: Called from DIABATIC. Calculates column total moisture flux convergence and water content. Works on one latitude pair at a time. Evaluates: VIMCON: the vertically integrated moisture flux convergence, by summing the flux convergence QCONG over sigma layers and dimensionalising to mm/day. VIMCONTR: as VIMCON but with truncated moisture flux convergence. VIMCONREF: as VIMCON for the reference state. COLWATER: the total column water, by summing over sigma layers and dimensionalising to mm. COLSAT: for diagnostic purposes only, this is the value COLWATER would take if the column was at saturation at every level.

Some values are accumulated into 2-d grid arrays for diagnostic output: VIMC=VIMCON, the vertically integrated moisture convergence (mm/day) VICW=COLWATER, the column total water (mm) VISF=COLWATER/COLSAT, the saturated fraction. (note that 2-d values in mm could also be expressed in kg/m2 ).

DEEPTEND(J,TGTDEEP,QGTDEEP): Called from DIABATIC. Returns deep convective tendencies for temperature and specific humidity. Works on one latitude pair at a time. See Chapter 4, section 4 for a description of the convection scheme.

This subroutine first sets the decision to trigger convection LTRIG as true, and then looks for reasons to set it to false. The first criterion depends on the difference VIMCONA between the smoothed vertically integrated moisture convergence VIMCONTR minus its reference value VIMCONREF. This difference must be positive and exceed a threshold for convection to be triggered.

The other optional criterion depends on vertical temperature differences in the lowest four layers of the model: specifically the mean of the bottom two layers minus the mean of the next two layers up. The “instability anomaly” BLSIA is the departure of this difference from its reference value. It must exceed a threshold for convection to be triggered.

If convection is triggered the column total rain falling in next TAUCOND period PPTTAU is calculated in mm as the convergence in mm/day times the period TACOND. PPTTAU is constrained not to exceed the total column water COLWATER and to be positive. It is also subject to a maximum value PPTTAUCAP, which is is constrained to approach asymptotically.

The value of PPTTAU is passed to PROFILEHEAT to evaluate the tendencies of specific humidity and temperature. The convective precipitation rate in mm/day associated with PPTTAU is stored for the current latitude pair for diagnostic 2-d output in PPTRATEDEEP.

PROFILEHEAT(J,FR,PPTTAU,QGT,TGT): Called from DEEPTEND and SSTTEND. Uses the precipitation PPTTAU(mm) that is passed to it and the associated rate FR, and returns tendencies for temperature and specific humidity for deep convective heating. Works on one latitude pair at a time.

For a given column total rain PPTTAU(mm) falling in next tau period associated with rate FR, this subroutine calculates the tendency QGT of gridpoint specific humidity based on pro-rata reduction of specific humidity at rate FR at each level. This operation is carried out on smoothed humidity if the option LTRUNCQ is enabled.

It also sets the tendency TGT of temperature by spreading the total latent heating over the predetermined profile PRHEAT(L). Along the way it accumulates the 3-d diabatic heating rate CONDHEAT (deg/day) for diagnostic output.

These calculations are done level by level and the grid point values of temperature TG and specific humidity QG are updated as we go. This subroutine also updates the total precipitation rate for diagnostics PPTRATE (mm/day).

SSTTEND: Called from DIABATIC. Returns tendencies for temperature and specific humidity associated with the response to an SST anomaly. Works on one latitude pair at a time. See Chapter 4, section 4c for a description of the way SST anomalies are implemented.

The purpose of this subroutine is to read SST data and, depending on the options set for ISSTRAN, calculate a precipitation rate anomaly associated with an anomaly in SST.

The subroutine starts by calculating the SSTA based on the nature of the variable SST. In the case ISSTREAD=1 the SSTA is calculated by subtracting SSTC from SST. Otherwise (ISSTREAD=0) SST is just used directly as the SSTA. At this point the SSTA can also be scaled by the factor SCALESSTA.

There different methods of for deducing a precipitation rate anomaly from the SSTA are set by ISSTRAN. The first three options translate the SST anomaly directly into a precipitation rates in mm/day (ISSTTRAN=1,2,3). The fourth passes the problem to the vertical diffusion scheme (ISSTTRAN=4). This is described in Chapter 4, section 4c.

For the first three cases the code actually uses the variable PPTTAU for rainfall in mm. And then it assumes that this amount of rain falls in one day by setting the rate FRSST appropriately. This is quite artificial and it is only done like this so that the subroutine PROFILEHEAT can be used to get the tendencies. For the fourth case (ISSTTRAN=4), this step is bypassed by setting PPTTAU=0. and the effect of the SSTA is calculated in the subroutine VDIFFTEND.

For the nonlinear transfer function, SSTC and the model divergence at \(\sigma\)=0.2, together with its reference value are used, along with a number of tuneable parameters. These parameters have not yet made their way into a namelist and this part of the code is work in progress. Once PPTTAU has been calculated, it is constrained by the land-sea mask to be only over the sea, and by the selective mask to either pick an ocean basin or cover the whole of the tropics. A constraint is added in the case that the convection scheme is being used, that the daily rainfall cannot exceed the column water total.

Finally PROFILEHEAT is called to set the tendencies of specific humidity and temperature associated with the SSTA: QGTSST and TGTSST as it does for the convection scheme, by spreading the heating into the deep profile and removing humidity pro-rata. But unlike the convection scheme call to PROFILEHEAT, the rate FRSST is now one day.

VDIFFTEND(J,UGTVDIFF,VGTVDIFF,TGTVDIFF,QGTVDIFF): Called by DIABATIC. Returns tendencies for zonal and meridional wind, temperature and specific humidity due to vertical diffusion. Works on one latitude pair at a time. For a description of the vertical diffusion see Appendix A section 5 and fig. A4.

This subroutine sets up damping rates due to vertical diffusion according to the damping rate profile PRDAMP, which is defined on sigma layer boundaries. DM and DP refer to the layer boundaries above and blow a given sigma level. Variables such as UGM and UGP are assigned to represent the values in fictitious layers above and below the vertical domain so that different boundary conditions can be imposed. We choose damped boundary conditions with these variables fixed at the reference values at the adjacent (top and bottom) levels.

It is at this point that the anomalous boundary flux due to SSTAs is added in the case that this is selected by setting ISSTTRAN=4. The SSTA is defined again as a local variable like in SSTTEND. Anomalies in temperature and humidity (the difference in saturation value) are calculated and added to the bottom boundary condition. The optional boost in land-surface humidity flux by the factor QGPFAC is also implemented here.

A simple centred difference is applied to find diffusive flux convergence and this is assigned to the tendencies of momentum, temperature and specific humidity. Only temperature and specific humidity grid variables are updated as there is no need to keep the momentum up to date.

LSRTEND(J,TGTLSR,QGTLSR): Called by DIABATIC. Returns height dependent tendencies for temperature and specific humidity associated with resolved condensation (large scale rain). Works on one latitude pair at a time. See Chapter 4, section 4c for a description of the large scale rain scheme.

This subroutine calculates saturated specific humidity QSAT at every level at a given grid point and compares it with the local specific humidity (or its smoothed value QGTR if LTRUNCQ is enabled). The supersaturation QDIFF is the difference between the two, and it is used directly to calculate the local specific humidity tendency QGTLSR using the rate FRCOND derived from the timescale TAUCOND. The associated latent heating rate is applied to the local temperature tendency TGTLSR. A limit is set to the maximum value of supersaturation that can be rained out at any given level. It is current;y set in the code as QDIFFCAP=50./16. * 1.e-4. For a standard value of TAUCOND=0.0625 (i.e. 1.5 hours) this means that the maximum precipitation rate possible (provided the limit is hit at every level) is 50 mm/day.

For diagnostic output, the rain rate PPTRATE (mm/day) is updated level by level. Note that this 2-d grid variable is the sum of all precipitation in the model. It is updated directly from this LSR scheme and also from the deep convection and SSTA schemes in PROFILEHEAT. Likewise the 3-d grid diagnostic variable for condensation heating CONDHEAT (deg/day) is updated level by level.

Finally the grid values of temperature TG and specific humidity QG are updated with the LSR tendencies.

CUSTOMMASK(JN,JS,IW,IE,WRKMASK): Called by INIVAR. Returns a 2-d mask for a region defined by latitude and longitude boundaries JN,JS,IW,IE.

A box is bounded by JN to the north, JS to the south, IW to the west and IE to the east. These are Gaussian latitudes and equally spaced longitudes with the first point on Greenwich. The box is filled with the value 1, so information is retained inside the box when the mask is applied. Outside this box the values are zero so this area is masked out. On the boundaries the value is 0.5 for a smooth transition from unmasked to masked areas.

This subroutine is called to define the SST mask RMASKSST: currently four options, the full tropics, and the Pacific, Atlantic and Indian tropical oceans (these three masks are contiguous). The boundaries of these masks for T42 and T31 are given in the include file setup.f.

This subroutine is also called to define the nudging mask RMASKNDG: the default values included in setup.f are for the full tropics.
